Item |
Specification |
|
Product |
Pattern color coated steel sheet / coil |
|
Base material |
Galvanized steel coil，Galvalume steel coil |
|
Thickness |
0.15-1.2mm |
|
Width |
100 -1250mm (according to your need) |
|
Coil Weight |
3-6tons |
|
Standard |
SGCH, SGCC, SPCC, DX51D, ASTM A653, EN10142, S350GD, etc |
|
Color |
Customers’ sample color or requirement |
|
Lacquer of painting |
PE, PVDF, SMP, HDP |
|
Surface |
anti-finger; with color coating of RAL series, in wooden pattern, in marble pattern or any special |
|
Zinc-coating |
30-200g/m2 |
|
Tensile strength |
According to the material |
|
Coil ID |
508mm/610mm |
|
Technique |
Cold rolled、hot dipped galvanizing、color coated |
|
Painting |
Top painting:5+12~25μm Back painting: 5~8μm |
|
Tolerance |
Thickness: +/-0.02mm Width:+/-2mm |
|
Package |
Standard seaworthy packing |
|
Payment |
T/T, L/C at sight |
|
Shipping time |
Within 30 days |
|
Application |
Building exterior application |
|
Building interior application |
|
|
Furniture |
|
|
Household application |
|
|
Steel window |
|
|
Others |
|
|
The special order can be negotiated. |
|
Package:
Seaworthy, waterproof paper + polyethylene rush inhibitor, the anti-rust paper, the ring of defense on inside and outside, steel belt, and the guard plate.
Usage of PPGI Brick pattern steel coils:
Electric appliances: Refrigerators, washing machines, switch cabinets, instrument cabinets, air conditioning, microwave oven, toaster, freezer, fluorescent light cover, distributor boxes, motor box, copy machine and so on.
Building and structure engineering: Vehicle internal plate, bus and truck backseat plate, transportation system and oil tank etc.
Agricultural equipment: Large barn, storage room, green house, drying machine for agriculture, flume and breeding utensil, silos, shell warehouse and so on.
Furniture and others: Automatic vending machine, recreation machine, chimney pipe, office equipment and garage etc.
Transportation industry: Car and train interiors, partitions, isolation fences, ships compartment plates, air purifiers, all kinds of piping, vessels equipped with all kinds of plates, oil purifier, distribution panels before the driver’s seat and so on.
